Shakespeare 4018-M VHF Antennas


THIS PRODUCT MUST SHIP TRUCK FREIGHT AND DOES NOT QUALIFY FOR ANY SHIPPING PROMOTIONS


Shakespeare Style 4018-M VHF Marine

19′ LENGTH, 9dB

PHASED 1/2-WAVE ELEMENTS IN A COLLINEAR ARRAY WITH A COAXIAL CHOKING SLEEVE TO SUPPRESS CABLE RADIATION

Same as Style 4018 with a special sleeve for mast mounting.Used primarily for land-based stations and on commercial vessels.

The top choice for charter boat captains and experienced sport fishing enthusiasts.This long-distance VHF antenna is rigid enough to stay erect in rough seas, yet exceptionally lightweight.

  • Brass and copper elements
  • Chrome-plated brass mid section ferrules and aluminum sleeve bottom ferrule
  • SO-239 connector at base
  • Suggested mount:Mast mount using supplied 1-1/3″ U-bolts.The 4018-M can be strapped to a larger mast if steel banding (not supplied) is used.
  • Two sections:Base 162″; Tip 66&quot:
  • Shakespeare Limited Warranty:2 years

Technical Specifications:

Frequency: VHF Marine band
Bandwidth: (within 2.0:1 VSWR) 3 MHz
SWR: 1.5:1 at 156.8 MHz
Impedance: (ohms): 50
Gain: 9 dB
Max Input (Watts): 25
DC Ground: NO
Termination: SO-239
Height (feet): 19
Polarization: Vertical
Radiation pattern: Omni-directional

Specifications:

Antenna Band = VHF
Ferrule Type = Chrome Plated
Length (Inches) = 19′
Cable Length (Feet) = 20′
Cable Type = RG-58
Color = White
Construction = Fiberglass
DB Gain (dB) = 9 dB

SHAKESPEARE VHF 19FT 4018-M 9DB NOT UPSABLE MUST GO TRUCK

Normalized SKU: 4018M

UPC Code: 719441100117
