Quick Bow Thruster BTQ 185-55 12v 55kgt D185mm 3.0kw #FGBT18055120K01

Description

Quick Windlass FGBT18055120K01 Thrusters

BTQ 185-55 DC Bow Thruster – 12V, 55kgf, 3kW

The Quick BTQ 185 is a single propeller bow thruster composed of a sturdy composite material. Some additional features of this unit are the solenoid is protected by a sturdy composite material, the gearbox is composed of bronze, the zinc anode is independent from the gearbox which allows an easy replacement and it is also equipped with an elastic coupling. This unit is sold complete with the bow thruster and users manual.

Bow Thruster kit contents: Thruster, Tunnel, 6M Cable, Fuse and Fuse
holder.

Specs:

• Propulsion System: Single propeller
• Tunnel Diameter: 7 9/32″
• Tunnel Length: (1000mm) 39.37″ (3.28′)
• Motor Power: 3 kW
• Voltage: 12V, optional 24V
• Fuse: 355A
• Thrust: 55kgf (121lb)
• Weight: 43.4 lb
• Limit thickness values of the tubes: min 11/64″ – max 1/4″
• Boat Size: 26-36′
• 3 Year Warranty

Normalized SKU: FGBT18055120K01

UPC Code: 8057090115444
