Description
| Mfr # | LFP122201K |
| Item | Automatic Demand Water System Pump |
| Body Material | Polypropylene |
| Check Valve | Viton |
| Inlet/Outlet | 3/8 in HB |
| Includes | (2) Piston, 3/8 in Inner Diameter Hose |
| Pressure On | 25 psi |
| Diaphragm Material | Santoprene |
| Max. Flow | 1.0 gpm |
| Voltage – Pumps | 12V DC |
| Flow | 1 gpm |
| Item – Industrial Pumps | Automatic Demand Water System Pump |
| Fuse Amps | 5 A |
| Standards | CSA Certified, IAPMO |
| Voltage | 12VDC |
| Type | Diaphragm |
| Power Type | Electric |
| Housing Material – Pumps | Polypropylene |
| Self-Priming | Yes |
| Max. Operating PSI | 35 |
| Pressure Off | 35 psi |
| Max. Pressure – Pumps | 35 psi |
| Diaphragm Material – Pumps | Santoprene(R) |
| Prime in Feet | 3 |
| Housing Material | Polypropylene |
| Discharge Port | 3/8 in Barbed |
| Diaphragm Chamber Design | 2 |
| Series | LP Plus |
| Flow Rate @ 0 psi | 1 gpm |
| Priming | Self-Priming |
| Flow Rate @ 60 psi | 0.7 gpm |
| Duty Cycle | Intermittent |
| Nameplate Voltage | 12V DC |
| Check Valve Material | Viton |
| Media Temperature (Maximum) | 110Degrees F |
| Pressure Switch | Yes |
| Operating Pressure (Maximum) | 35 psi |
| Discharge Connection Type | Barbed |
| Flow Rate (Maximum) | 1 gpm |
| Suction Port | 3/8 in Barbed |
| Current | 3.5 A |
| Intake Connection Type | Barbed |
