Description
- Ideal as a DC ground tie point or positive bus, these heavy duty, 500 amp rated bus bar assemblies feature 5/16″” studs on 1″” centers in 1/4″” thick copper bar for common connection/distribution of large wire gauges and accommodate 5/16″” ring terminals.
- One combination model features two 5/16″” studs and eight #8 screws, accommodating multiple size wire terminals.
- All bus material is nickel-plated copper.
- A clear insulating protective cover is provided to prevent short circuits and provide visibility of lugs.
- The mounting bases are keyed for interlocking and may be mated with the terminal strips (described above). Conductive parts are captured and recessed away from the mounting surface. Use #8 or #10 screws for mounting.
| Model | Qty. of 5/16″” Studs | Base Size |
| BB-2 | 2 | 3 1/16″” x 1 1/2″” |
| BB-2/8 | 2 plus 8 – #8 screws | 6 1/16″” x 1 1/2″” |
| BB-5 | 5 | 6 1/16″” x 1 1/2″” |
| BB-8 | 8 | 9 1/16″” x 1 1/2″” |
These heavy-duty, 500-ampere rated current busbar assemblies are ideal for use as DC ground connection points or positive busbars, with 5/16″” studs on a 1″” center 1/4″” thick copper core…!!!!—-
