Description
Maretron Fluid Pressure Sensor Transducers work with the Maretron FMP100 which will adapt up to six pressure Transducers to the NMEA 2000 network
Maretron 05000PSI01 Attributes
Maretron 05000PSI01 Technical Bulletins
- FPM100 Datasheet.pdf
Pressure Transducer Mechanical Drawing
|
Pressure Transducer Specifications Part Number |
Range |
Accuracy |
Type |
|
PT-0-3PSI-01 |
0 to 3 PSI (0.21 bar) |
± 2% Full Scale |
Gauge |
|
PT-0-5PSI-01 |
0 to 5 PSI (0.34 bar) |
± 2% Full Scale |
Gauge |
|
PT-0-10PSI-01 |
0 to 10 PSI (0.69 bar) |
± 2% Full Scale |
Gauge |
|
PT-0-50PSI-01 |
0 to 50 PSI (3.45 bar) |
± 1% Full Scale |
Gauge |
|
PT-0-100PSI-01 |
0 to 100 PSI (6.89 bar) |
± 0.5% Full Scale |
Gauge |
|
PT-0-500PSI-01 |
0 to 500 PSI (34.47 bar) |
± 0.5% Full Scale |
Absolute |
|
PT-0-3000PSI-01 |
0 to 3000 PSI (206.84 bar) |
± 0.5% Full Scale |
Absolute |
|
Specification |
Value |
|
Operating Temperature |
-40°C to 105°C |
|
Storage Temperature |
-40°C to 105°C |
|
Proof Pressure |
2.4Full Scale |
|
Burst Pressure |
2.4Full Scale |
|
Reverse Voltage Protection |
±16V over 5 Minutes |
|
Construction |
304L stainless steel |
|
Pressure/Temperature Cycles |
0 to FS @ 8Hz; and ?40°C to 105°C for > 1.8×106 cycles |
|
Thermal Shock |
105°C to ?40°C, 0.5 hr soaks at Temp. (2s Transfer) for 300 cycles |
|
Vibration |
100 to 2000 Hz, 20g Sinusoidal, 3 Axes for 144 hours |
|
EMC Compatibility |
10 Volts/meter per EN 61000-4-3 |
|
Humidity |
85°C and 90% to 95% R. H. for 250 hours |
|
Weight |
85g |
Compatible Fluids / Gases:
- Refrigerant
- Motor Oil
- Diesel
- Hydraulic Fluid
- Brake Fluid
- Water
- Waste Water
- Hydrogen
- Nitrogen
- Air
Operating Temperature:
- -5°C to 60°C
Media Temperature:
- -40°C to 125°C
Construction:
- 1.4301 (AISI304) Housing
- 1.4542 (AISI630) Pressure Connection
- 1.4542 (AISI630) Sensor
Cable:
- IP67, PVC
Cable Length:
- 3.28 feet (1.0m)
Vibration:
- 15 g RMS (20 – 2000 Hz)
- 25 g sin (80 – 2000 Hz)
- 1 oct./min, (1x @ 25°C)
Shock:
- 50 g/11 ms
EMC Compatibility:
- EN 61000-6-3
- EN 61000-6-2
Humidity:
- Max. 95% relative
Weight:
- 50g (1.8 oz)
!!!!—-
