Magnum MS2000L 2000W Inverter 12v W/100A PFC Charger #MS2000-L-U
Original price was: $2,124.36.$299.99Current price is: $299.99.
Description
Magnum Energy MS2000-L-U Inverters
Magnum MS2000-L 2000 Watt, 12vDC Inverter with 100 Amp PFC Charger
Model: MS2000-L
- Pure Sine Wave — Power your TVs, computers, and other sensitive electronics without worry. The MS Series provides clean, reliable inverter power with low total harmonic distortion (THD) of less than 5%.
- Accessible Design — The extra large AC access cover with terminal screw block and 360° DC connection terminals with covers make this inverter accessible.
- Versatile Mounting — Mount the MS Inverter/Charger on a shelf, bulkhead, or even upside down.
- Lightweight — The lightweight aluminum base and cover also provides noise reduction and corrosion resistance.
- Multiple Ports — The MS Series provides multiple ports, including an RS485 communication port for network expansion, and a remote port.
- Convenient Switches — The MS Series comes with an on/off inverter-mounted switch with an easy-to-read LED indicator.
The Magnum-Dimensions MS Series Inverter/Charger is a pure sine wave inverter designed specifically for the most demanding mobile, backup, and off-grid applications. The MS Series Inverter/Charger is powerful, easy-to-use, and best of all, cost effective. Power Factor Corrected (PFC) Charger: Our PFC charger is built into all of our inverter/chargers. It uses less energy from a generator than a standard charger — 25-30% less AC current than standard chargers.
Specifications
| General | |
| Transfer relay capability | 30 ACC max. each inpu |
| Five stage charging capability | Bulk, Absorb, Float, Equalize (requires remote), and Battery Saver™ |
| Battery temperature compensation | Standard with available temp sensor connected (battery temp 0-50° C) |
| Internal cooling | 0 to 120 cfm variable speed drive using dual 92mm brushless DC fans |
| Overcurrent protection | Yes, with two overlapping circuits |
| Overtemperature protection | Overtemperature protection |
| Corrosion protection | Yes, PCB’s conformal coated, powder coated chassis/top, and stainless steel fasteners |
| Inverter | |
| Input battery voltage range | 9 – 16.8 VDC |
| AC output voltage accuracy | 120 VAC ± 5% |
| Output frequency and accuracy | 60 Hz ± 0.1 Hz |
| Total Harmonic Distortion (THD) | < 5% |
| 1 msec surge current (amps AC) | 50 |
| 100 msec surge current (amps AC) | 33 |
| 5 sec surge power (real watts) | 3300 |
| 30 sec surge power (real watts) | 3100 |
| 5 min surge power (real watts) | 2800 |
| 30 min surge power (real watts) | 2200 |
| Maximum continuous input current | 267ADC |
| Inverter efficiency (peak) | 90.6% |
| AC Relay Transfer time (minimum) | 16 msecs |
| Power Consumption – searching | <8 watts |
| Power Consumption – inverting (no load) | 25 watts |
| Output Waveform | Pure Sine Wave |
| Charger | |
| Continuous output at 25° C | 100 ADC |
| Charger efficiency | 85% |
| Power factor | > .95 |
| Input current for continuous rated output | 15 AAC |
| Dimensions l x w x h | 13.75in x 12.65in x 7in |
Normalized SKU: MS2000LU
