Description
The Lewmar ‘Wavespring’ self-tailer combines their renowned and gentle wave grip feature with self adjusting springs. It handles today’s smaller diameters, as well as the traditional larger Dacron composite ropes. A sleek, minimum-friction feeder arm provides absolute snag-free operation.
Mounting Instructions
5 x M6 (1/4 in) c’sk head screws on 121mm (4 3/4 in) PCD. Lewmar recommend that the rope enters onto the drum at an angle of 5to 10to the base axis of the winch. To achieve this angle it may be necessary to use a base wedge when installing the winch. This product is Made to Order. |
| |
|
|
| Gear Ratio1st/2nd |
Power Ratio1st/2nd |
Weight(lb) |
| 1.9:1/5.8:1 |
13.2:1/40.2:1 |
14.3 |
|
|
|
| Drum Diameter D(in) |
Base Diameter B(in) |
Height H(in) |
Line Entry L(in) |
Line Size(in) |
| 2 15/16 |
5 13/16 |
6 13/16 |
3 1/8 |
5/16?1/2 |
|
