JL Audio MX Series 500w 4 Channel Full-Range Amplifier – MX500/4
Original price was: $449.99.$90.00Current price is: $90.00.
Description
MX Series 500w 4 Channel Full-Range Amplifier – MX500/4
125 W x 4 @ 2 Ω / 70 W x 4 @ 4 Ω – 14.4V
Engineered specifically for powersports applications, the 4-channel MX500/4 amplifier employs our high-speed NexD™ switching design to deliver plenty of clean power, without straining charging systems. Its tiny, cast aluminum chassis is highly resistant to corrosion, with an IPX7 water-resistance rating, making it perfect for motorcycles, ATVs, or other utility vehicles.
Generating a solid 70W x 4 into 4 ohms (14.4V, 1% THD), the MX500/4 is fully bridgeable, so it can be used as a 3-channel amplifier, or as a 2-channel amplifier producing a potent 250W x 2 into 4 ohms.
Other features include independent front and rear crossovers with selectable full-range, high-pass or low-pass filter controls and a dual-range input section that accepts a wide range of input voltage levels, from line-level all the way to high-power speaker level signals.
This amplifier features a rugged powder-coated finish, a gasketed cover for the controls and stainless steel hardware for durability.
Specifications:
- Channels – Available: 4
- Watts: 500w
- Box Dimensions: 4″H x 8″W x 13″L WT: 4.25 lbs
- UPC: 699440984089
Owner’s Manual (pdf)
