Humminbird XM-14-HW-MSI-T MEGA SI+/DI+ Dual Spectrum CHIRP TM Transducer w/Temp f/SOLIX™

Description

Transom Mount, MEGA Side Imaging+, MEGA Down Imaging +, 800kHz/455k kHz and 1.2 MegaHertz and Dual Spectrum CHIRP 2D Sonar with a CHIRP range of 150 to 220kHz. Features built-in temperature sensor.

Humminbird 7102921 Attributes

• Mounting Location: Transom Mount
• Number Of Pins: 14 Pin
• Depth: 1200 Feet
• Frequency Range: 150/ 220 kHz Full Dual Spectrum CHIRP Frequency, 455/ 800 kHz, 1.2 MHz Operating Frequency
• Cable Length: 20 Feet

Humminbird 7102921 Features & Benefits

• Compatible With: All APEX Models, All SOLIX CHIRP MEGA SI+ G2 And G3 Models
• Dual Spectrum CHIRP Frequencies: Full: 150 To 220 Kilohertz, Narrow: 180 To 240 Kilohertz, Wide: 140 To 200 Kilohertz
• Dual Spectrum CHIRP Max Depth: 1200 Feet
• Features Built-In Temperature Sensor
• Limited 1 Year Warranty

Humminbird 7102921 Installation Instructions

• 532508-4_B XM T Fixed Transom Transducer Installation Guide.pdf

Humminbird 7102921 Warranties

• Humminbird 1-Year Limited Warranty.pdf

Humminbird 7102921 Technical Bulletins

• 532651-1EN_A Transducer Resource Guide.pdf
• 532651-1EN_A Transducer Resource Guide.pdf

XM-14-HW-MSI-T MEGA SI+/DI+ Dual Spectrum CHIRP TM Transducer with Temp for SOLIX™

MEGA Side Imaging+ Transom Mount Transducer supports MEGA Imaging+/800kHz/455kHz and Dual Spectrum CHIRP 2D Sonar with a CHIRP range of 150-220kHz. Includes built-in temperature sensor, rugged composite design, all metal bracket and 20’ cable.

Features:

• This accessory is compatible with the following Humminbird products: SOLIX 10 CHIRP MEGA SI+ GPS G2, SOLIX 12 CHIRP MEGA SI+ GPS G2, SOLIX 15 CHIRP MEGA SI+ GPS G2.
• Dual Spectrum CHIRP Frequencies: Full: 150-220 kHz, Narrow: 180-240 kHz, Wide: 140-200 kHz
• Dual Spectrum CHIRP Max Depth: 1200ft (365m)
• MEGA Side Imaging Frequencies – Max Range (side-to-side): 455kHz: 440-500 kHz – 800ft (244m), 800kHz: 790-850 kHz – 250ft (76m), MEGA SI+: 1075-1150 kHz – 400ft (122m)
• MEGA Down Imaging Frequencies – Max Depth: 455kHz: 440-500 kHz – 400ft (122m), 800kHz: 790-850 kHz – 250ft (76m), MEGA DI+: 1075-1150 kHz – 200ft (61m)

Frequency: 83/200/455/800kHz and 1.2 MHz including built-in temperature sensor, sturdy composite design, full metal bracket and 20′ cable.!!!!—-
