Description

GFS10 Marine Fuel Sensor

Add fuel tracking capabilities to your Garmin chartplotter and optimize your boat’s fuel economy. The GFS 10 tracks fuel flow use and sends the data to your chartplotter via the Garmin CANet ® or NMEA 2000 ®. Unlike other fuel flow sensors, the GFS 10 will include fuel level sensing capability when connected to an existing analog fuel gauge or resistive fuel tank sensor. Maximum fuel flow rate for the GFS 10 is 50 Gallon Per hour, and the minimum flow rate is 2 Gallon Per Hour.

Garmin 100067100 Attributes

• Used To: Track Fuel Flow And Sends The Data To Chart Plotters
• Fitting Type: 3/8 Inch Barbed
• Flow Rate: 2 Gallons Per Hour
• Pressure Range: 0.5 PSI At 20 Gallons Per Hour/ 1.0 PSI At 40 Gallons Per Hour
• Input Voltage: 10 To 22 Volt
• Certified: U.S. Coast Guard Approved
• Includes: Mounting Hardware/Fuel Filter/Reusable Stainless Steel Hose Clamp/NMEA2000 To CANet Adapter Cable

Garmin 100067100 Features & Benefits

• Add Fuel Tracking Capabilities To Your Garmin Chartplotter And Optimize Your Boat’s Fuel Economy
• GFS 10 Tracks Fuel Flow Use And Sends The Data To Your Chartplotter Via The Garmin CANet ® Or NMEA 2000
• Design: 3/8 Inch Barbed Fittings
• Fire Resistant And Complies With U.S. Coast Guard Standards
• Limited 1 Year Warranty

Garmin 100067100 Installation Instructions

• Technical_Reference_for_Garmin_NMEA_2000_Products_EN-US (5).pdf
• GFS10FuelSensor_QuickReferenceGuideMulti-lingual.pdf
• ISPI_Marine_15.pdf
• GFS_10_Install_Multi.pdf
• GFS10FuelSensor_SensorConfiguration.pdf

Garmin 100067100 Warranties

• garmin-marine-warranty-policy.pdf

GFS™ 10 Fuel Sensor

Add fuel tracking capabilities to your Garmin chartplotter and optimize your boat’s fuel economy. The GFS 10 tracks fuel flow use and sends the data to your chartplotter via the Garmin CANet or NMEA 2000.

Unlike other fuel flow sensors, the GFS 10 will include fuel level sensing capability when connected to an existing analog fuel gauge or resistive fuel tank sensor. Maximum fuel flow rate for the GFS 10 is 50 gallons per hour, and the minimum flow rate is two gallons per hour.

Note:

• GPSMAP 4xx and 5xx series CANet compatible units require a CANet kit to complete the connection.
• The GFS 10 does not work with diesel engines.
• The GFS 10 does not work with fuel injected gas engines with a fuel return line.

The GFS 10 fuel sensor adds fuel tracking to the Garmin plotter and optimizes the fuel economy of the ship. GFS 10 tracks fuel flow usage and sends the data to the chartplotter via Garmin CANet or NMEA 2000. Unlike other fuel flow sensors, GFS 10 will have a fuel level detection function when connected to an existing analog fuel gauge or resistive fuel tank sensor. . Note: GPSMAP 4xx and 5xx series CANet compatible devices need CANet kit to complete the connection. GFS 10 is not suitable for diesel engines. GFS 10 is not suitable for fuel-injected gasoline engines with fuel return pipes.!!!!—-
