Blue Sea 7717 ML-RBS Remote Battery Switch w/Manual Control Auto-Release – 24V

Description

Auto Releasing ML-Series Remote Battery Switch with SPST Switching Provides 500 Ampere switching and features of current ML Remote Battery Switches, but can be controlled with SPST or SPDT switch for applications where a normally open relay is desired.

Blue Sea 7717BSS Attributes

• Type: Push/ Pull
• Activation Type: Manual
• Continuous Ampere Rating (A): 500 Amp
• Surge Ampere Rating (A): 700 Amp
• Installation Type: Bolt-On

Blue Sea 7717BSS Features & Benefits

• Manual Override Knob Provides An Added Level Of Safety Allowing Control With Or Without Power And Offering LOCKED OFF Capability For Servicing
• LED Output To Remotely Indicate Switch State
• Silver Alloy Contacts Provides High Reliability For Switching Live Loads
• 3/8 Inch -16 Tin-Plated Copper Studs For Maximum Conductivity And Corrosion Resistance
• 7/8 Inch Stud Length Accepts Multiple Cable Terminals
• Label Recesses For Circuit Identification
• No Supplier Warranty

Blue Sea 7717BSS Installation Instructions

• 990180170-006.pdf

ML-RBS Remote Battery Switch with Manual Control Auto-Release – 24V

• Manual override knob provides an added level of safety allowing control with or without power and offering LOCKED OFF capability for servicing
• LED output to remotely indicate switch state – requires optional LED
• 3/ 8″-16 tin-plated copper studs for maximum conductivity and corrosion resistance
• 7/ 8″ (22mm) stud length accepts multiple cable terminals
• Label recesses for circuit identification
• Silver alloy contacts provide high reliability for switching live loads

Auto Releasing ML-Series Remote Battery Switch with SPST Switching Provides 500A switching and features of current ML Remote Battery Switches, but can be controlled with SPST or SPDT switch for applications where a normally open relay is desired

Specifications

Control Circuit Connection:Tinned Wire

Nominal Voltage:24V DC

Manual Control:Yes

Coil Function: Auto releasing

Mounting: #10

Amperage Operating Current:8mA when OFF/13mA when ON

Amperage Operating Current when changing state: <4A (40 ms) Control Circuit Voltage: 20.2 to 32.9V DC Continuous Rating: 500A Intermittent Rating: 700A (5 min) Cranking Rating: 10 sec 2500A Cranking Rating: 1 min 1100A Minimum Operating Temperature: -10° C Maximum Operating Temperature: 50° C Cable Size to Meet Ratings: 2x (4/0) Live Current Switching: 300A @ 12V DC 10,000 Cycles Master Control Switch Capability: Yes Mechanical Endurance: 100,000 Cycles Switching Cycles: 100000 Terminal Ring Diameter Clearance: 1.18″ (29.97mm) Terminal Stud Length: 0.875″ (22.23mm) Terminal Stud Size: 3/8-16 (M10) Terminal Stud Torque: 140 in-lb (15.82 Nm) Weight: 1.75lb (0.79 kg)

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

The ML-RBS remote battery switch with manual control and automatic release function-24V manual control button provides a higher security level, allows control in the case of power-on or power-off, and provides…!!!!—-
